Selected Dimensions
A. OVERALL LENGTH
7.9 ft in
2410 mm
B. OVERALL WIDTH
3.8 ft in
1170 mm
C. HEIGHT W/ RAILS
7.4 ft in
2260 mm
D. WHEELBASE
6.1 ft in
1850 mm
E. GROUND CLEARANCE
3.9 in
100 mm
F. MAX PLATFORM HEIGHT
26 ft in
7920 mm
G. PLATFORM WIDTH
45.3 in
1150 mm
H. PLATFORM LENGTH
89 in
2260 mm
I. DECK EXTENSION
35.8 in
910 mm
Specification
SYSTEM VOLTAGE
24 V
NUMBER OF BATTERIES
4
OPERATING WEIGHT
4312.2 lb
1956 kg
HYDRAUILC SYSTEM FLUID CAPACITY
3.8 gal
14.2 L
MAX SPEED
2.2 mph
3.5 km/h
TIRE SIZE
15x5x11
TIRE FILL/TYPE
Solid non-marking
MAX WORKING HEIGHT
32.5 ft in
9920 mm
MAX PLATFORM HEIGHT
26 ft in
7920 mm
MAX PLATFORM WEIGHT CAPACITY
1000.9 lb
454 kg
PLATFORM LENGTH
89 in
2260 mm
PLATFORM WIDTH
45.3 in
1150 mm
LIFT TIME
30 sec
LOWER TIME
38 sec
DECK EXTENSION
35.8 in
910 mm
OVERALL LENGTH
7.9 ft in
2410 mm
OVERALL WIDTH
3.8 ft in
1170 mm
HEIGHT W/ RAILS
7.4 ft in
2260 mm
HEIGHT W/O RAILS
5.5 ft in
1680 mm
WHEELBASE
6.1 ft in
1850 mm
TURNING RADIUS
7.5 ft in
2290 mm
GROUND CLEARANCE
3.9 in
100 mm
